High Powerful Waterproof Moving Head Light 500W Rated Power For Big Stage

Product Categories

Guangzhou Sunway Entertainment Equipment Co., Ltd.

Contact Now

Name: High Powerful Waterproof Moving Head Light 500W Rated Power For Big Stage
Brand: Weinas
Price: 1 USD

Brand Name : Weinas

Model Number : Beam350

Certification : CE,ROHS

Place of Origin : Guangzhou, China

MOQ : 2 Pieces

Price : High Quanlity & Reasonable Price

Payment Terms : T/T, , L/C

Supply Ability : 1000pcs/month

Delivery Time : 3-12 Workdays Depends On Quantity

Packaging Details : Export Carton Or Flight Case

Lamp : Yodn 17R 350W or 16R

Display : Touch Screen With 180 degree Revered available

DMX Channle : 16/12CHS

Lens : Quartz Glass Optical Lens

Color Wheel : 14 colors+white

1 Gobo Wheel : 13 static gobos+white

Prism : 1PCS 24 facet prisms and 1PCS 8 facet prisms

Pan : 540 Degree 16bit

Tilt : 270 Degree 16bit

Strobe : 1-13 times / second

Dimmer : 0-100% dimmer

Frost : 0-100% Frost

IP Level : IP20

Control Mode : Auto-run, Master-slave, Sound-active Mode

Packing : Carton or Flight Case

Other Function : Lamo Off / On

Contact Now

High Powerful Beam Moving Head Stage Light 17R 350W Beam Spot Wash Moving Head stage Light

Weinas-Beam350

Function Specifications

Voltage	AC220V-240V 50/60Hz
Lamp	YODN 17r 350w, 16R 330W
Rated Power	500W
Len	0-5°Optical lens group
Display	Touch Screen with 180 degree reversed available, with four buttons
Control mode	16/12 Channels optional,Art-net light control protocol and wireless DMX512 control (optional)
Pan Movement	540 degree (16Bit scanning accuracy)
Tilt Movement	270 degree (16Bit scanning accuracy)
Color wheel	14 dichroic filters + open, with half color effect
Static gobo wheel	17 gobos + open
Prism	1 pcs 24 facet prism with 3 layers + 1 pcs 8 facet circular prism with 3 layers, rotating in both directions at variable speed
Strobe	Double and pole strobe maximum reaches 13 times per second, random strobe and pulse strobe optional
Dimmer	0%-100% linear dimmer
Foggy	0~100% linear foggy
IP rate	IP20 high efficiency switch power supply
Other Function	Other function: Lamp on/off function and reset through controller. Auto-run, Master/slave, Sound active mode.

DMX Channles Function

Standard	Simplify	Function Description
CH1	CH1	Pan
CH2	CH2	Tilt
CH3	*	Pan fine
CH4	*	Tilt fine
CH5	*	Pan& Tilt speed
CH6	CH3	focus
CH7	CH4	Strobe
CH8	CH5	Dimmer
CH9	CH6	Color wheel
CH10	CH7	Static gobo wheel
CH11	CH8	Static gobo wheel Shaking
CH12	CH9	Prism 1(24 prism)+ Prism 2(8 prism with 3 layers)
CH13	*	Prism 1 rotation
CH14	CH10	Prism 2 rotation
CH15	CH11	Frost
CH16	CH12	Lamp off 100-105, on 200-205, Reset 255

Effet And Testing Pictures

High Powerful Waterproof Moving Head Light 500W Rated Power For Big Stage
